Description

Nr. Art.	Width (mm)	Weight (kg)	Capacity (m3)	Teeth (pcs)
A501.120A	1200	295	0,65	6
Two hydraulic cylinders
A501.120	1200	305	0,65	6
A501.130	1300	310	0,70	6
A501.140	1400	315	0,76	7
A501.150	1500	325	0,81	7
A501.160	1600	340	0,86	8
A501.180	1800	385	0,97	8
A501.200	2000	425	1,08	9
A501.220	2200	445	1,19	10
A501.240	2400	470	1,30	11
Features
Cover thickness: 5 mm
Side thickness: 10 mm
Cutting edge HB500/110mm x 16 mm
Top teeth are welded to grab
Additional options
Split grab
